External Drive Piezo Transducer (AC)



Part No. | Diameter Φ (mm) | Height (mm) | Max. Input Voltage (V) | Rated Voltage (VAC) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Capacitance @ 1KHz (pF) | Operating Tempature (°C) | Housing | Weight (g) |
---|---|---|---|---|---|---|---|---|---|---|
CPT3010C25TP | 30 | 10 | 30 Vp-p | 3 Vrms | 90 @ 10cm | 2500 | 25000 ± 30% | -20 ~ +70 | PBT | 6 |
Please contact us for the datasheet of this product.
