Piezo Buzzer (DC)


| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VDC) | Rated Voltage (VDC) | Max Rated Current (mA) | Min Sound Output (dBA) | Tone Nature | Resonant Frequency (Hz) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CPB2309HC34NP-W | 23.5 | 9.5 | 3 ~ 20 | 12 | 8 | 90 @ 10cm | Continuous | 3400 ± 500 | -20 ~ +60 | Noryl | 4 |
Please contact us for the datasheet of this product.
