Magnetic Buzzer (DC)

CMB1209
Part No.Diameter Φ (mm)Height (mm)Operating Voltage (VDC)Rated Voltage (VDC)Max Rated Current (mA)Min Sound Output (dBA)Tone NatureResonant Frequency (Hz)Operating Tempature (°C)TerminalHousingWeight (g)
CMB1209AC23NP129.51.3 ~ 21.53075 @ 10cmContinuous2300 ± 400-10 ~ +50PinNoryl2
Please contact us for the datasheet of this product.
