SMD Magnetic Transducer (AC)
| Part No. | Length (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CSMT0804D2731LSQ | 8.5 X 8.5 | 3.6 | 2 ~ 4 | 3.6 | 80 | 16 ± 3 | 85 @ 10cm | 2731 | -20 ~ +70 | LCP | 0.37 |
Please contact us for the datasheet of this product.
