SMD Magnetic Transducer (AC)
| Part No. | Length (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|
| CSMT0904D2731LR | Φ 9 | 4.5 | 2 ~ 5 | 3.6 | 100 | 16 ± 2.4 | 88 @ 10cm | 2670 | -30 ~ +70 | LCP | 0.38 |
Please contact us for the datasheet of this product.
