Self Drive Piezo Transducer (DC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VDC) | Rated Voltage (VDC) | Max Rated Current (mA) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|
| CIT2510H32TP | 25 X 24 | 10 | 3 ~ 30 | 12 | 20 | 90 @ 10cm | 3200 ± 500 | -20 ~ +125 | PBT | 3.5 |
Please contact us for the datasheet of this product.
