Magnetic Transducer (AC)
| Part No. | Diameter Φ (mm) | Height (mm) | Operating Voltage (VAC) | Rated Voltage (VAC) | Max Rated Current (mA) | Coil Resistance (Ω) | Min Sound Output (dBA) | Resonant Frequency (Hz) | Operating Tempature (°C) | Terminal | Housing | Weight (g) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CMT1810F2048NPR | 18 X 14 | 10.5 | 3 ~ 10 | 6 | 40 | 60 ± 9 | 90 @ 10cm | 2000 ~ 2500 | -30 ~ +85 | Pin | Noryl | 7 |
Please contact us for the datasheet of this product.
